A few words .....
It's been said a few times but, anyone considering this should realize that an adapter plate is needed if you want an 82mm throttle body, or a flange could be welded to the s/c inlet.
Then you will also need to modify the intake "Y" pipe outlet to match the larger throttle body.
Last, you are increasing the amount of airflow so you will need to monitor your short & long term fuel trims. The computer can only compensate to a point. A custom tune may not be mandatory, but do not assume you are safe without verifying via wideband and monitoring your fuel trims.
If this all sounds like too much for you, consider the 80mm throttle upgrade.

Pic. illustrate the parts needed – this set from Eurocharge showing a bolt-on solution.
The electrical connection you have on the SLIDE from the M273 fits without any modification to pins but the Audi RS6 has a different plug and another assignment (and other pins). A wiring harness adapter is recommended. VW p/n# 1J0 973 713 - It can be found here as connector kit 17025:
You will need a new housing on the compressor with an 80 mm. out-let. In EPC this is called a PIPE LINE and the MB part number is A113 140 09 12. The price is about 240€. Also an adapter plate between the new 80 mm. PIPE LINE and the 82 mm. SLIDE; as well as for the 82 mm. throttle body from Audi RS6 is necessary. This adapter plate can optional be welded onto the PIPE LINE and machined to fit and if you go for that, then you can use your original PIPE LINE.
Following original Mercedes Benz parts will be needed:
- GASKET; ELECTRONIC GAS ACTUATOR TO INTAKE MANIFOLD: A273 141 06 80
- GASKET; INTAKE FITTING ON COMPRESSOR: A113 141 07 80
- GASKET; INTAKE HOUSE: A113 141 15 80
- HOUSING; DISTRIBUTOR LEFT AND RIGHT: A113 094 02 03
- CLAMP; DISTRIBUTOR TO HOSE; A008 997 44 90 – CHECK THIS
- GASKET; ELECTRONIC GAS ACTUATOR TO INTAKE MANIFOLD: A112 141 13 80 (not needed if adaptor plate is being welded)
Ten o-rings come in the package, you need only two for each application. Remove the plastic retainer and rubber seal from the y-pipe, replace with two new quad style o-rings, and assemble.
Note: This is for the MB 82mm throttle house being used in conjunction with the 80mm y-pipe. I pulled the rubber gasket and plastic ring out of the inlet connection. It measures XXXX with these removed. Mcmaster.com has o-rings with an inside measurement XXX and outside of XXX which should work.
*This I am still working on*
Since you will have to remove the compressor from the engine to make this modification you will need new gaskets for this too:
- GASKET; CHARGE AIR LINE/COMPRESSOR ON CYLINDER HEAD: A113 141 09 80
- GASKET; LEFT; A113 098 01 80
- GASKET; RIGHT; A113 098 00 80

82 mm. setup for SL55AMG from 2003
The 82 mm. throttle body from the M273 has the MB part number A273 141 03 25 (In EPC called a SLIDE) Bosch number 0280750 183. The throttle body cannot be order from Bosch but only be bought as new for about 800€ at the MB dealer.
The 82 mm. throttle body from Audi RS6 has the WW/Audi part number 077 133 062A Bosch number 0280 750 047. Audi's throttle body will cost about 720€ new.
